Operating System

Embedded Linux

Online visitors

Supports 4 visitors at the same time

CPU/Image sensor

Ingenic T40,2 MP Dual view,1/3 inch 1080p progressive scan CMOS sensor

Minimum illumination

0.5 Lux(Color mode), 0.1 Lux(B&W mode)

Lens

4mm-6mm

Night Vision

IR-CUT with auto-switching, dual light source, irradiation distance 15-30 meters

Compression standard

H.264 main profile/H.264 main profile/Motion-JPEG/JPEG

Data rate

Mainstream:1080p(1920*1080)@25fps,
Substream:360p(640360)@15fps

Bit rate
/maximum frame rate

1284096kbps/25fps

Image adjustment

Adjustable brightness and contrast

Audio Input

Built-in - 38dB microphone

Audio Output

Built-in 8 2W speaker

Audio Sampling frequency
/bit width

8KHz/16bit

AudioCompression standard/Bit Rate

G.711/64kbps

Network interface

10Mbps/100Mbps adaptive /RJ45 interface

Network protocol

TCP/IP, HTTP, TCP, UDP, DHCP, DNS, NTP, RTSP, P2P etc.

Wireless network

IEEE802.11b/g/n

Wireless frequency

2.4G

Wireless
security encryption

64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption

PTRotation angle

Horizontal 350 /Vertical 90 , can be installed with 360 rotation

Preset position

Supports 16 presets (mobile app only supports 5)

Storage functions

Supports T-Flash card(max supports 256GB); Cloud Storage; NVR;NAS

Alarm detection

Support for motion detection, human detection, human tracking, fire point detection, and smoke and fire detection.
